Toumei T5 3D Mini Smart DLP Short Throw Outdoor Portable Projector







☑ 1 x T5 Mini DLP 3D 4k Projector Device
☑ 1 x Power adapter
☑ 1 x IR remote control
☑ 1 x Tripod
☑ 1 x User manual
☑ 1 x HDMI cable (gift)

Item | Product Characteristic | Product parameters |
OPTICS | Projection technology | America DLP technology |
Display Chip | TI 0.2 inch WVGA DMD*RGBLED (With Off-axis Ray Machine)>100% | |
Brightness | 150ANSI Lumens / 2000 lumens | |
Lamp | OSRAM LED Lamps | |
Uniformity | >90% | |
FOFO Contrast Ratio | 1000:1 | |
Standard Resolution | WVGA 854*480 | |
3D | Support 3D function(DLP-LINK) | |
PROJECTION | Throw Ratio | 1 meter: 39 inches |
Throw Range | 30-300 inches | |
Throw Distance | 1-6Meter(s) | |
Aspect Ratio | 4:3/16:9/16:10 | |
Keystone Correction | Supports automatic and manual | |
Projection Methods | Front Projection, Rear Projection, Hanging cast | |
Texture of material | Plastic ABS+ electroplating + metal | |
Focus mode | Electric motor focusing | |
Built-in loudspeaker | 8 Ω 2W*2 | |
Sound effects | Dolby sound effect | |
SYSTEM PARAMETERS | CPU | MStar6A638 Decode 4K H.265/VP9 4K*2K/30HZ |
Clock Speed | 64 bits CPU: Cortex A53 Two nuclei GPU: Mali-450mp4 | |
RAM | 2G DDR3 | |
ROM | 32GB eMMC | |
Operating System | Android 6.0 | |
Bluetooth | Bluetooth 4.2 | |
WIFI | 2.4G / 5.0G dual-band WIFI | |
Remote Control | Infrared remote control and support connect the 2.4g wireless remote control and the mouse | |
Power input parameters | 12V-3A DC | |
Input support | USB, IR | |
INTERFACE | Extended Memory | Support TF card and SSD Hard Dish |
USB | USB HOST 2.0*1 USB HOST 2.0*1 | |
TF Card | Maximum supported 32G | |
HDMI | HDMI 2.0 input | |
USB | Able to read data from USB hard drive support mouse and keyboard access | |
Headphone Output | Audio output, 3.5mm connectors (can connect headphones or speakers) | |
DC Input | Power adapter: DC 12V 3A | |
ELECTRICAL SPECIFICATIONS | Total Power Consumption | 25W |
Battery Capacity | 7.4V 4200mAh | |
Power Performance | AC100-240V,50/60Hz built-in battery | |
OTHER PARAMETERS | Product Size | 180*90*22mm |
Package Size | 250*180*110mm | |
Net Weight | 420g | |
Package Weight(1set) | 1.06Kg | |
Package Weight(20sets/box) | 22Kg | |
Carton Size(20sets/box) | 470*440*325mm |
Turn on the projector
Focus

How to choose the language?

How to adjust the screen?

How to connect with WiFi?

How to airplay your phone?



Turn on the speaker, Turn on the bluetooth of projector, connect them together

How to connect your computer?
Connect by HDMI cable.
How to connect your gamepad?
Connect by HDMI cable.
Plug mouse in USB port

How to watch 3D movie?
Take a shutter 3D glasses


What is the best throw distance
2-3Meters
It can support what kind of video format ?
MPEG-1 MPEG-2 MPEG-4Real-time video decoder, H263,H264,H265,1080P, Sorenson Spark,WAV
It can support what kind of audio format?
MP3,WMA,MP2,0GG,AAC,M4A,MA4,FLAC,APE,3GP,WAV
It can support what kind of image format?
Jpg, Png Bmp etc.
How to control your projector?
By mouse, by Remote controller
How to download Apps?
By google play store or Aptoide
How to fix the problem of system?
Please send email to support@toumeipro.com
Need more help
Call us: +86 138 2457 8022
Live chat: WhatApp +86 137 1470 3093
Send email: support@toumeipro.com
